Overview

1. The device provides a connection port.

2. The module has a built-in voltage stabilization circuit, operating voltage 9~36V, and is easy to connect.

3. It adopts advanced digital filtering technology, which can effectively reduce measurement noise and improve measurement accuracy.

4. It also provides various host computers, user manuals, and development manuals needed by users, minimizing the development time for various needs.

5. It supports 485 & CAN interfaces. Users can choose the optimal connection method. The serial port rate is adjustable from 4800bps to 230400bps, and the CAN serial port rate is adjustable from 3K to 1M.

6. Application areas: It can be widely used for bearing vibration measurement and real-time monitoring of rotating machinery such as submersible pumps, fans, steam turbines, coal mills, oxygen generators, generators, centrifuges, compressors, water pumps, and motors.

7. Three-axis displacement, three-axis velocity, and three-axis frequency outputs meet users' needs for comprehensive vibration and impact measurement, and determine whether the measured object (motor, water pump) is damaged. In case of machine malfunctions caused by factors such as bearing wear, bearing cracking, poor dynamic balance, or misalignment, the vibration sensor can detect the fault in advance and issue a warning, preventing the machine from continuing to operate under adverse conditions and causing damage, thus resulting in economic losses.

8. Multiple installation methods: Magnetic connection, secure and stable, simple and convenient installation and disassembly.

9. Industrial-grade temperature sensing element, faster and more accurate acquisition of ambient temperature.

Specifications

Basic parameters

• Vibration velocity: the speed at which the vibration point of an object moves when it vibrates

• Amplitude: The amplitude of the vibration point when the object vibrates (vibration displacement)

• Vibration frequency: The number of times an object shakes per unit time during vibration. The vibration frequency measurement range is 1Hz~2000Hz

Product size

Application

Download

Video
