Overview

1. Employs advanced digital filtering technology to effectively reduce measurement noise and improve measurement accuracy.

2. Universal DC power interface (5.5*2.5), supports a wide voltage input of 9-24V.

3. Maximum data output rate of 10Hz, adjustable from 1 to 10Hz.

4. Standard RJ45 Ethernet port connection enables long-distance communication.

5. IP67 waterproof rating significantly reduces environmental interference.

6. Shock and drop resistant plastic casing makes the product less prone to damage.

Specifications

1. Voltage: 9V~24V

2. Current: 40mA (12V)

3. Dimensions: 55mm x 36.8mm x 24mm

4. Communication Method: RJ45 Ethernet port

5. Measurement Dimensions: Acceleration: 3D, Velocity: 3D, Displacement: 3D, Frequency: 3D

6. Measurement Range: Vibration Velocity: 0~600mm/s, Vibration Acceleration: ±16G, Vibration Displacement: 0~30000um, Vibration Frequency: 5-2000Hz

7. Data Output Content: Three-axis vibration (velocity + acceleration + displacement + frequency), chip temperature, version number (only three-axis vibration acceleration and chip temperature are output in raw data mode)

8. Data Output Frequency: 1, 2, 5, 10Hz (up to 32kHz in raw data mode)

9. Axial Direction: The direction of the linear motion indicated by the arrow is the axial direction.

Application
